SilverStone ST65F-ES230 650W (80+ White) – ATX

Brand :

RM209.00
  • High efficiency with 80 PLUS certification
  • 24/7 continuous power output with 40℃ operating temperature
  • Class-leading single +12V rail
  • Active PFC Circuitry
  • PCIe 8pin and PCIe 6pin connector support
  • Silent running 120mm fan with 18dBA

In stock

SKU: PSUSILVERSTONEST65F Categories: , , , , Tags: , , , , ,

Specifications

Model No.
SST-ST65F-ES230
Max. DC Output
650W
Power density
360W per liter
Load Range
Output
 +3.3V +5V +12V +5VSB -12V
Max.(Amps)
 20A 20A 50A 2.5A 0.3A
Peak (Amps)
 / / / / /
Min.(Amps)
 0A 0A 0A 0A 0A
Range (%)
 ±5% ±5% ±5% ±5% ±10%
Line Reg.(%)
 ±1% ±1% ±1% ±1% ±1%
Ripple(mVp-p)
 50mV 50mV 120mV 50mV 120mV
Color
Black（Lead-Free Paint）
Combined +3.3V & +5V
120W
Combined +12V
600W
Input Voltage
180V~264V
Input Frequency Range
47Hz~63Hz
PFC
Active PFC（PF>0.9 at full load）
Efficiency
82% ~ 85% at 20% ~ 100% loading
MTBF
100,000 hours
Operating temperature
0°C ~ 40°C
Protection
Over power protection
Over voltage protection
Short circuit protection
Connectors
1 x 24 / 20-Pin motherboard connector（500mm）
1 x 8 / 4-Pin EPS / ATX 12V connector（750mm）
4 x 8 / 6-Pin PCIe connector（”500mm / 150mm” x 2）
4 x SATA connector（”500mm / 150mm” x 2）
3 x 4-Pin Peripheral connector（500mm / 150mm / 150mm）
1 x 4-Pin Floppy connector（500mm / 150mm / 150mm / 150mm）
Cooling System
Single 120mm silent fan
Form factor
Noise Level
18 dBA minimum
Dimension
150 mm (W) x 86 mm (H) x 140 mm (D)
5.91″ (W) x 3.39″ (H) x 5.51″ (D)
Weight
1.42 kg
Certification
80 PLUS
Other
GPU Support list
Compatible with ATX12V v2.4

* All black flat cable version
● Specifications presented on this page contains most recent revisions and may differ from those printed on retail boxes or manuals.
